Stud.io/LDraw/LDD Sets

Here are a number of educational LEGO® sets with all the parts laid out in CAD software. This could be useful for a number of purposes, including designing things from parts in each set without physically having the set, or if you want to model something you've built from a set in CAD without having to go hunting for parts.

Orignially these sets were only available as .lxf files for use in LEGO® Digital Designer. However, since LDD is deprecated and has become increasingly difficult to run on modern systems, in July 2020 I added files for all sets in .ldr (LDraw) and .io (Studio) formats. Moving forward, the .ldr and .io versions should be considered the canonical versions for each set, and future sets will only be added with .ldr and .io files.

You are free to use these files however you like, create derivitave works, etc. I ask only that if you publish them or a derivitave work, you credit me with a link back to this page.

Update Log

12 July 2020 - Updated set images, added files in LDraw and Stud.io formats.
July/August 2021 - Added more sets: SPIKE Prime, Motorized Mechanisms, WRO.

Mindstorms Sets

Note that the rechargable battery pack adds an additional unit to the height of the NXT and EV3 bricks. The models of the bricks in LDD show the bricks in their shorter configuration, using AA batteries, so you'll have to keep this in mind when modeling the NXT or EV3 bricks in LDD.

SPIKE Prime Set (45678)

Studio file requires Philo's 'Spike Prime' parts pack. LDraw file is missing 28T gears.

Download:

SPIKE Prime Expansion Set (45680)

Studio file requires Philo's 'Spike Prime' parts pack. LDraw file is missing 20T and 28T gears and curved racks.

Download:

SPIKE Prime Base & Expansion Sets (45678 + 45680)

The SPIKE Prime base & expansion sets, together in a single file. Studio file requires Philo's 'Spike Prime' parts pack. LDraw file is missing 20T and 28T gears and curved racks.
